9VA8 | pdb_00009va8

Crystal Structure of Human Cathepsin B with a L-peptide substrate

PDB DOI: https://doi.org/10.2210/pdb9VA8/pdb

Classification: PEPTIDE BINDING PROTEIN
Organism(s): Homo sapiens, synthetic construct
Expression System: Mammalian expression vector BsrGI-MCS-pcDNA3.1
Mutation(s): Yes

Deposited: 2025-06-03 Released: 2026-05-06
Deposition Author(s): Li, M., Li, T., Chen, K.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.209 (Depositor), 0.210 (DCC)
R-Value Work:
0.178 (Depositor), 0.180 (DCC)
R-Value Observed:
0.180 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9VA8

This is version 1.0 of the entry. See complete history.

Literature

Transcending stereochemical boundaries: ambidextrous cleavage of D- and L-peptide enantiomers by natural eukaryotic proteases

Li, M., Chen, K., Zhang, W., Han, J., Guo, M., Zhu, X., Zheng, J., Li, T., Dang, B.

(2026) Vita

DOI: https://doi.org/10.15302/vita.2026.03.0022

Macromolecule Content

Total Structure Weight: 28.24 kDa
Atom Count: 2,189
Modeled Residue Count: 258
Deposited Residue Count: 258
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cathepsin B	A	254	Homo sapiens	Mutation(s): 1 Gene Names: CTSB, CPSB EC: 3.4.22.1
UniProt & NIH Common Fund Data Resources
Find proteins for P07858 (Homo sapiens) Explore P07858 Go to UniProtKB: P07858
PHAROS: P07858 GTEx: ENSG00000164733
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P07858
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
(ACE)YY(F3V)	B [auth C]	4	synthetic construct	Mutation(s): 0

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.209 (Depositor), 0.210 (DCC)
R-Value Work: 0.178 (Depositor), 0.180 (DCC)
R-Value Observed: 0.180 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 30.617	α = 90
b = 75.096	β = 90
c = 97.642	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
PHASER	phasing
HKL-3000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-05-06

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-05-06
Type: Initial release
